Product Details:
|
| Alloy: | 1060, 1100, 3003, 6061 Alloy | Type: | 1060, 1100, 3003, 6061 Aluminum Alloy Sheet, Aluminum Alloy Plate |
|---|---|---|---|
| Common Used Thickness: | 0.2-300 Mm | Width: | 800, 1000, 1220, 1250, 1500 Or As You Required.. |
| Length: | 500-16000mm, Or As You Required | Sample: | Yes, Free Sample |
| Customized Service: | Yes | Moq: | 500 Kgs |
| High Light: | 6061 Alloy 2mm Aluminium Checker Plate,1500 Width 2mm Aluminium Checker Plate,1500 Width 6061 tread plate |
||
Specifications:
| Aluminium Embossed Sheet, Aluminum Tread/Checkered sheet plate | |
| Alloy | 1050/1060/1100/3003/5754/5083/6061/6063/6060/6082/8011 |
| Temper | H14,H18,H24,H32 ,H112, H114, T4,T6 ,T651,O |
| Thickness (mm) | 0.7mm to 20mm |
| Width (mm) | Up to 1500mm |
| Length (mm) | Up to 6000mm |
| Standard | GB/T14001-2004,ISO14001:2024, GB/T19001-2008,ISO9001:2008,SGS |
| MOQ | 5ton |
| Application | 1)Decorated inside and outside the car /building frame, windows, doors, ceiling, decorating panel and curtain wall |
| 2)Household appliances: refrigerators, microwave ovens, audio equipment, etc. | |
| Delivery time | 20-35 days after received the payment |
| Payment terms | L/C T/T |
Chemical composition:
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | OTHERS | OTHERS | Al |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | — | 0.05 | 0.03 | 0.03 | — | 99.5 |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | — | 0.04 | 0.03 | 0.03 | — | 99.7 |
| 1100 | 0.95 Si + Fe | 0.05-0.20 | 0.05 | — | — | 0.1 | — | 0.05 | 0.15 | 99 | |
| 2024 | 0.5 | 0.5 | 3.8-4.9 | 0.30-0.9 | 1.2-1.8 | 0.1 | 0.25 | 0.15 | 0.05 | 0.15 | Rem. |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | — | — | 0.1 | — | 0.05 | 0.15 | Rem. |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0-1.5 | 0.8-1.3 | — | 0.25 | — | 0.05 | 0.15 | Rem. |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0-1.5 | 0.20-0.6 | 0.1 | 0.25 | 0.1 | 0.05 | 0.15 | Rem. |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50-1.1 | 0.1 | 0.25 | — | 0.05 | 0.15 | Rem. |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | 0.1 | — | 0.05 | 0.15 | Rem. |
| 5252 | 0.08 | 0.1 | 0.1 | 0.1 | 2.2-2.8 | — | 0.05 | — | 0.03 | 0.1 | Rem. |
| 6061 | 0.40-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.05 | 0.15 | Rem. |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-6.1 | 0.2 | 0.05 | 0.15 | Rem. |
Mechanical Property:
| Grades and status | Tensile strength (25°C MPa) |
Yield Strength (25°C MPa) |
Hardness force 500kg 10mm |
Elongation thickness 1.6mm(1/16in) |
| 2024-T351 | 470 | 325 | 120 | 20 |
| 5052-H112 | 175 | 195 | 60 | 12 |
| 5083-H112 | 180 | 211 | 65 | 14 |
| 6061-T651 | 310 | 276 | 95 | 12 |
| 7050-T7451 | 510 | 455 | 135 | 10 |
| 7075-T651 | 572 | 503 | 150 | 11 |
Common used alloy and applications:
1235, 1050, 1060, 1100: High Aluminum Content
Applications: Conventional Industry
3003, 3004: Rust-Proof, Suitable for Humid Environments
Applications: Air Conditioning, Refrigerator, Car Bottom, and Other Humid Environments
5052, 5005, 5083, 5754: Low Density, Anti-Stretch, Strong Extension
Applications: Aircraft Tank, Conventional Industry, Deep Processing Of Oxidation.
6061 6082: Excellent Interface Features, Corrosion Resistance, Easy To Coat, High Strength
Applications: Aircraft Parts, Camera Parts, Couplings, Marine Accessories And Hardware, Electronic Accessories And Fittings, Decorative Or Various Hardware, Hinge Head, Head, Brake Piston, Hydraulic Piston, Electrical Accessories, Valves And Valve Parts.
Packing & Delivery
Packed with pallets ,wooden cases woven bag, PVC or PE, and steel frame support on wood pallet or other seaworthy export packing in 20' or 40' container as per customers' requirements
The inner size of container is below:
20ft GP: 5.8m(length) x 2.3m(width) x 2.18m(high) about 24-26CBM, 25MTS
40ft GP: 11.8m(length) x 2.3m(width) x 2.18m(high) about 54CBM, 25MTS
40ft HQ: 11.8m(length) x 2.3m(width) x 2.72m(high) about 68CBM, 27MTS
