Product Details:
|
| Type: | Aluminum Sheet, Plate, Coil | Alloy: | 3003, 3004, 3005 |
|---|---|---|---|
| Temper: | O - H112 | Thickness: | 0.1-500mm |
| Width: | 200-2300mm | Length: | 500 To 16000mm, Or As You Requested |
| Sample: | Can Be Provided | Note: | Customized Service Is Available |
| Delivery Time: | 15-35 Days | ||
| High Light: | 2000mm Width 3000 Series Aluminum Sheet Coil,2.0mm 3000 Series Aluminum Sheet Coil,2000mm Width flat aluminum sheet |
||
Specifications:
| Aluminium Alloy | Thickness (mm) | Width (mm) | Temper |
| 1050,1060,1100 | 0.2-2.0 | 800-2000 | H14,H16,H24,H26 |
| 3003,3004,3105 | 0.2-2.0 | 800-2000 | H14,H16,H24,H26 |
| Standard Size | Standard thickness:0.3-1.2mm | ||
| Surface | Standard width: 914mm/1000/1200/1220mm | ||
| Size can be produced as per clients requirement | |||
| Surface | Mill Finish, Flat, Smooth, Stucco Emboss(Orange Peel), Corrugation | ||
| Back Lamination | Polykraft Paper, Polysurlyn, Kraft Paper, Craft Paper | ||
| Polykraft Thickness | about 0.1mm | ||
| Corrugation Type | 6x32mm( wave height 6mm ,and wave distance 32mm) | ||
| Quality Standard | ASTM B209,EN573-1 | ||
| MOQ Per Size | 1 tons, 500kgs can be accepted for trial order. | ||
| Payment Terms | TT, LC, DP at sight | ||
| Delivery Time | Within 35 days after receipt LC or deposit | ||
| Material Quality | Tension Level, Flat, Free Of Defects Like Oil Stain, Roll Marks, Waves, Dents, Scrath,Etc A+++ Quality | ||
| Application | Heat Insulation Moisture Barrier, Oil Field | ||
| Packaging | Standard export worthy wooden pallets, and standard packing is about 2 .5tons/pallet or 100 feet one roll | ||
| Coil Id:508mm, eye to wall or eye to sky as per clients requirement | |||
| or 100 feet one roll and each roll packed in one carton box, one 20' container can be loaded about 280 rolls | |||
Chemical Composition:
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | OTHERS | OTHERS | Al |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | — | 0.05 | 0.03 | 0.03 | — | 99.5 |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | — | 0.04 | 0.03 | 0.03 | — | 99.7 |
| 1100 | 0.95 Si + Fe | 0.05-0.20 | 0.05 | — | — | 0.1 | — | 0.05 | 0.15 | 99 | |
| 2024 | 0.5 | 0.5 | 3.8-4.9 | 0.30-0.9 | 1.2-1.8 | 0.1 | 0.25 | 0.15 | 0.05 | 0.15 | Rem. |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | — | — | 0.1 | — | 0.05 | 0.15 | Rem. |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0-1.5 | 0.8-1.3 | — | 0.25 | — | 0.05 | 0.15 | Rem. |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0-1.5 | 0.20-0.6 | 0.1 | 0.25 | 0.1 | 0.05 | 0.15 | Rem. |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50-1.1 | 0.1 | 0.25 | — | 0.05 | 0.15 | Rem. |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | 0.1 | — | 0.05 | 0.15 | Rem. |
| 5252 | 0.08 | 0.1 | 0.1 | 0.1 | 2.2-2.8 | — | 0.05 | — | 0.03 | 0.1 | Rem. |
| 6061 | 0.40-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.05 | 0.15 | Rem. |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-6.1 | 0.2 | 0.05 | 0.15 | Rem. |
Mechanical Property:
| Mechanical Property | ||||||||
| ALUMINUM | Grade | Normal | Temper | Tensile Strength | Yield Strength | Elongation% | Brinell Hardness | |
| ALLOY | Temper | N/mm² | N/mm² | Plate | Bar | HB | ||
| 1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 |
| 1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 | |
| Al-Cu | 2019 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - |
| (2XXX) | 2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 |
| Al-Mn | 3003 | O | 110 | 40 | 30 | 37 | 28 | |
| (3XXX) | 3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 |
| Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 |
| Al-Mg | 5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 |
| (5XXX) | 5083 | O,H112,H | O | 290 | 145 | - | 20 | - |
| Al-Mg-Si | 6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 |
| (6XXX) | 6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 |
| Al-Zn-Mg | 7003 | T5 | T5 | 315 | 255 | 15 | - | 85 |
| (7XXX) | 7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 |
3003
Used for processing parts that require good formability, high corrosion resistance and good weldability, or work that requires these properties and higher strength than 1XXX series alloys, such as kitchenware, food and chemical product processing and Storage devices, tanks and tanks for transporting liquid products, various pressure vessels and pipes made of thin plates.
3004
The body of all-aluminum cans requires higher strength parts than 3003 alloy, chemical product production and storage devices, thin sheet processing parts, construction processing parts, construction tools, various lighting components.
3105
Room partitions, baffles, movable house panels, gutters and downpipes, thin sheet forming parts, bottle caps, bottle stoppers and other architectural decorative parts.
The anodic oxide film is brighter than the oxide film on 3003 alloy and is in harmony with the color tone of 6063 alloy.
Packaging:
Standard seaworthy package. Wooden pallets with plastics protection for the coil and sheet, or to be packed as your requests.
| Container Loading Capacity | |||||
| Type | Length | Width | Height | Volume | Max Weight |
| 20FT GP | 5.8m | 2.13m | 2.18m | 24-26CBM | 25MT |
| 40FT GP | 11.8m | 2.13m | 2.18m | 54CBM | 25MT |
| 40FT HP | 11.8m | 2.13m | 2.72m | 68CBM | 26MT |
| FCL(full container load), LCL(less than container load), or Bulk-cargo. | |||||
| According to the quantity or volume, you can choose! | |||||
