Product Details:
|
| Type: | Aluminum Strips | Alloy: | 3003 |
|---|---|---|---|
| Width: | 20-1600mm | Hardness: | O |
| Grade: | 1000 Series | Brand: | YOWO |
| Sample: | Can Be Provided For Free | Temper: | O - H112 |
| High Light: | Temper T351 aluminium flat strips,Temper T351 aluminum strip roll,1500mm length aluminium flat strips |
||
Specifications:
| Product name | Aluminum strip |
| Alloy / Grade | 1000 series, 3000 series, 5000 series, 6000 series, 7000 series, 8000 series |
| Temper | 0-H112, T3-T8, T351-T851 |
| Thickness | 0.13-6.5mm |
| Width | 3-2600mm |
| Length | As per your requirements |
| Applications | Industry, decorations, building, packing, pressing etc.. |
| Surface treatment | Mill finish, coated, powder coated, anodized, polished mirror, embossed etc.. |
| Tolerances | As per your requirements |
| Delivery time | 7-30 days after receiving deposit or Original LC. |
| MOQ | 500kgs |
| Loading port | Shanghai port, Qingdao port |
| Coil ID | As per your requirements. |
| Prices terms | FOB, CIF, CFR(CNF), EXW etc. |
| Payment terms | LC, TT, West Union etc. |
Why Choose Aluminum for transformer?
1. Economic, means less cost for better achievements.
2. Conductivity of Copper is good, but Aluminum's is as double as copper at the same price.
3. Aluminum is more flexible that means it easier to wind and place in winding process.
4. Aluminum is lighter, easy to place.
In North America ,aluminum is the moost popular choice of winding material for low-voltage, dry-type transformers.
| Mechanical Property | ||||||||
| ALUMINUM | Grade | Normal | Temper | Tensile Strength | Yield Strength | Elongation% | Brinell Hardness | |
| ALLOY | Temper | N/mm² | N/mm² | Plate | Bar | HB | ||
| 1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 |
| 1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 | |
| Al-Cu | 2019 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - |
| (2XXX) | 2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 |
| Al-Mn | 3003 | O | 110 | 40 | 30 | 37 | 28 | |
| (3XXX) | 3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 |
| Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 |
| Al-Mg | 5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 |
| (5XXX) | 5083 | O,H112,H | O | 290 | 145 | - | 20 | - |
| Al-Mg-Si | 6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 |
| (6XXX) | 6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 |
| Al-Zn-Mg | 7003 | T5 | T5 | 315 | 255 | 15 | - | 85 |
| (7XXX) | 7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 |
We(Henan YOWO Industrial) have more than 10 years experiences of Aluminum sheet, Aluminum foil and Aluminum strip products. We fully understand our customers' needs and requirements, and strictly in accordance with international standards such as ASTM, EN_AB, JIS, GB for the production of various grades of aluminum products.
We make sure each piece of aluminum roll No Burrs, No Scratches of Round Edge to fit for transformer winding.
Any size can be customized. No matter you need large quantity or small quantity, or trial order, we'll all treat it seriously. Give us one chance to be your reliable supplier in the near future!
