Product Details:
|
Type: | Aluminum Strips | Alloy: | 1000 Series |
---|---|---|---|
Width: | 20-1600mm | Hardness: | O |
Brand: | YOWO | Sample: | Can Be Provided For Free |
Temper: | O - H112 | Delivery Time: | 7-30 Days After Confirm Order |
High Light: | Anti Corrosion flexible aluminum strips,0.3mm flexible aluminum strips,0.3mm flat aluminum strips |
The alloy composition of 1060 aluminium is
Aluminium: 99.6% min
Copper: 0.05% max
Iron: 0.35% max
Magnesium: 0.03% max
Manganese: 0.03% max
Silicon: 0.25% max
Titanium: 0.03% max
Vanadium: 0.05% max
1060 aluminium alloy
1060 aluminium alloy is an aluminium based alloy in the "commercially pure" wrought family (1000 or 1xxx series). It is fundamentally very similar to 1050 aluminium alloy, with the difference coming down to 0.1% aluminium by weight. However, while both 1050 and 1060 are covered by the same ISO standard, they are covered by different ASTM standards.
As a wrought alloy, it is typically formed by extrusion or rolling. It is commonly used in the electrical and chemical industries, on account of having high electrical conductivity, corrosion resistance, and workability. It has low mechanical strength compared to more significantly alloyed metals. It can be strengthened by cold working, but not by heat treatment.
Alternate designations include Al99.6 and A91060. It is described in the following standards:
ASTM B 209: Standard Specification for Aluminum and Aluminum-Alloy Sheet and Plate
ASTM B 210: Standard Specification for Aluminum and Aluminum-Alloy Drawn Seamless Tubes
ASTM B 211: Standard Specification for Aluminum and Aluminum-Alloy Bar, Rod, and Wire
ASTM B 221: Standard Specification for Aluminum and Aluminum-Alloy Extruded Bars, Rods, Wire, Profiles, and Tubes
ASTM B 483: Standard Specification for Aluminum and Aluminum-Alloy Drawn Tube and Pipe for General Purpose Applications
ISO 6361: Wrought Aluminium and Aluminium Alloy Sheets, Strips and Plates
Type | Aluminum Sheet/Foil/Strip |
Grade & Temper | 1070/1060/1050/1350 O |
Thickness |
0.2-2.0mm (other thickness can be produced) |
Width | 20-1650mm |
Inner Diameter | 150/300/400/500mm |
Conductivity(%IACS) | ≥61.5 |
Reisitivity number(Ω·mm2/m) | ≤0.02825 |
Elongation(%) | >23 |
Tensile Strength(Mpa) | >76 |
Density in 20℃ | 2.7g/cm3 |
Why Choose Aluminum to produce transformer?
1. Economic, means less cost for better achievements.
2. Conductivity of Copper is good, but Aluminum's is as double as copper at the same price.
3. Aluminum is more flexible that means it easier to wind and place in winding process.
4. Aluminum is lighter, easy to place.
In North America ,aluminum is the moost popular choice of winding material for low-voltage, dry-type transformers.
We(Henan YOWO Industrial) have more than 10 years experiences of Aluminum sheet, Aluminum foil and Aluminum strip products. We fully understand our customers' needs and requirements, and strictly in accordance with international standards such as ASTM, EN_AB, JIS, GB for the production of various grades of aluminum products.
We make sure each piece of aluminum roll No Burrs, No Scratches of Round Edge to fit for transformer winding.
Any size can be customized. No matter you need large quantity or small quantity, or trial order, we'll all treat it seriously. Give us one chance to be your reliable supplier in the near future!
